Cellular Automata with Deep Dream and Object Morphing

A Python-based creative visualization tool that combines cellular automata, Deep Dream effects, continuous zoom, and object morphing to create mesmerizing visual experiences from images and videos.

Features

• Cellular automata-based image processing
• Deep Dream integration for enhanced visual effects
• Continuous zoom effects
• Object detection and morphing using YOLO and EfficientDet
• Support for both image and video input
• GPU acceleration support (CUDA)
• Stable Diffusion integration for object generation
• Face detection and landmark recognition

Two Ways to Use

1. Headless Mode (New - Lightweight)

The gnarly package provides CA-only batch processing with minimal dependencies:

# Install minimal dependencies
pip install -r requirements-core.txt

# Run headless batch processing
python -m gnarly input.jpg -o output.mp4 --frames 300 --rule Conway

Headless CLI Options:

python -m gnarly input.mp4 -o output.mp4 \
  --frames 300          # Frame count (for images)
  --rule Conway         # CA rule: Conway, HighLife, Seeds, Custom, DivisorRule
  --grid-scale 4        # CA cell size in pixels
  --blend-alpha 0.3     # Blend factor for live cells
  --fps 15              # Output FPS
  --max-dimension 800   # Max frame dimension

2. Interactive Mode (Full-Featured)

The original main.py includes Deep Dream, object detection, and real-time controls:

# Install full dependencies (requires GPU)
pip install -r requirements.txt

# Run interactive mode
python main.py input_file [--output_file OUTPUT] [--creativity 0.5]

Requirements

Headless mode (minimal):

• Python 3.x
• numpy, opencv-python, Pillow, tqdm

Interactive mode (full):

• Python 3.x
• CUDA-capable GPU (recommended)
• See requirements.txt for full dependencies

Installation

1. Clone this repository
2. Install dependencies:

   # For headless CA-only processing
   pip install -r requirements-core.txt

   # For full interactive mode with Deep Dream
   pip install -r requirements.txt

Interactive Mode Usage

python main.py input_file [--output_file OUTPUT_FILE] [--deep_dream_iterations ITERATIONS] [--deep_dream_lr LEARNING_RATE] [--creativity CREATIVITY_LEVEL]

Arguments

• input_file: Path to the input image or video file
• --output_file: (Optional) Path to the output video file. Defaults to input_name_dream.mp4 in keep/
• --deep_dream_iterations: (Optional) Number of Deep Dream iterations (default: 30)
• --deep_dream_lr: (Optional) Learning rate for Deep Dream (default: 0.02)
• --creativity: (Optional) Creativity level for object detection/morphing (0.0 to 1.0, default: 0.5)

Interactive Controls

During rendering, you can use the following keyboard controls to adjust parameters in real-time:

• Space: Switch between different cellular automata rules
• R: Reset the grid, image, and zoom settings
• Left/Right Arrow: Decrease/Increase grid scale
• Up/Down Arrow: Increase/Decrease the divisor value
• B/N: Increase/Decrease blend alpha (mixing between states)
• O: Toggle object detection and morphing
• Z: Toggle continuous zoom effect
• [/]: Decrease/Increase creativity level
• Esc: Exit the program

How It Works

1. The program processes input media using cellular automata rules
2. Deep Dream effects are applied to enhance visual patterns
3. Object detection identifies interesting elements in the scene
4. Stable Diffusion generates variations of detected objects
5. Continuous zoom creates an infinite zoom effect
6. All elements are combined into a seamless, evolving visual experience

Package Structure

gnarly/
  __init__.py           # Package marker, version
  __main__.py           # Entry point: python -m gnarly
  cli.py                # Argument parsing
  config.py             # Configuration dataclasses

  core/
    ca.py               # Cellular automata rules and CAEngine
    io.py               # VideoReader/Writer classes
    utils.py            # blend_images, zoom_image

  effects/
    base.py             # Effect protocol
    ca_effect.py        # CA overlay effect

  runners/
    headless.py         # Batch processing loop

Cellular Automata Rules

• Conway: Classic Game of Life (B3/S23)
• HighLife: Game of Life variant (B36/S23)
• Seeds: Explosive growth pattern (B2/S)
• Custom: Modified survival rules (B3/S234)
• DivisorRule: Neighbor count modulo divisor

Credits

This project was developed by Devin Venable in collaboration with AI assistance.

Video Examples

View all video examples on our video showcase page.

Here are some preview thumbnails of the outputs:

Nature and Landscapes

Abstract and Stylized

Other Examples

License

This project is open source and available under the MIT License.
