Mesh Stealth Transfers

Hackathon Track: Private Payments ($15,000 Prize)

Offline, unlinkable SPL token transfers via Bluetooth mesh. Two phones in airplane mode can exchange value that settles on Solana with zero on-chain correlation between sender and receiver.

The Innovation

First stealth address implementation for Solana + First offline payment system for Solana

• Stealth Addresses: EIP-5564 adapted for ed25519/Solana - one-time addresses derived from receiver's meta-address
• Post-Quantum Security: Hybrid X25519 + ML-KEM 768 (NIST FIPS 203) using Apple CryptoKit
• Offline Mesh Payments: BLE mesh with store-and-forward and automatic settlement when online
• E2E Encrypted Chat: Double Ratchet with post-quantum hybridization over mesh

Key Features

1. Stealth Addresses

Sender derives a one-time stealth address from receiver's public meta-address. The transaction destination has zero on-chain link to the receiver's identity.

Receiver generates: M (spending) + V (viewing) → meta-address
Sender derives: P_stealth = M + SHA256(ECDH(r, V))*G
Include ephemeral R in memo → receiver scans and recovers

2. Post-Quantum Security (Hybrid Mode)

Optional ML-KEM 768 hybridization provides quantum resistance while maintaining classical security:

• Combined secret: S = SHA256(S_classical || S_kyber)
• 66% faster scanning than pure ECDH per arxiv.org/abs/2501.13733
• Uses Apple CryptoKit MLKEM768 (iOS 26+) - no external dependencies

3. Offline BLE Mesh Payments

• CoreBluetooth peer discovery and message relay
• TTL-based flooding with message deduplication
• Store-and-forward queue for offline peers
• Automatic settlement when connectivity restored

4. E2E Encrypted Chat

• Double Ratchet protocol (Signal-style)
• Post-quantum hybridization (X3DH + ML-KEM)
• Perfect forward secrecy and post-compromise security
• Works entirely over BLE mesh - no internet required

5. Privacy Protocol Integration

• Privacy Cash and ShadowWire protocol support
• WebView bridge for protocol interaction
• Automatic mixing with 1-5 hops before settlement

Demo

Peer Discovery Radar

Interactive radar visualization showing nearby mesh peers with RSSI-based positioning and PQ capability indicators.

Payment Flow

1. Tap nearby peer on radar
2. Request their meta-address (automatic)
3. Enter amount and send
4. Payment queued for mesh delivery
5. Auto-settles when either device comes online

Stealth Wallet

• Shield: Move SOL from main wallet to stealth addresses
• Unshield: Consolidate stealth payments back to main wallet
• Activity feed with PQ badges for quantum-resistant transactions

Quick Start

Requirements

• iOS 26+ (required for CryptoKit MLKEM768)
• Xcode 16+
• Two iOS devices with Bluetooth for mesh testing
• Solana Devnet (automatic airdrop available)

Build

git clone https://github.com/Spizzerp/smesh.git
cd smesh/MeshStealth
open MeshStealth.xcodeproj

1. Select your development team in Signing & Capabilities
2. Build and run on two physical iOS devices
3. Tap "Request Airdrop" to get devnet SOL
4. Discover each other on the mesh radar
5. Send a stealth payment!

Test StealthCore Library

cd MeshStealth/Packages/StealthCore
swift test

Architecture

┌─────────────────────────────────────────────────────────────┐
│                        iOS App                               │
│  ┌─────────────┐  ┌─────────────┐  ┌─────────────────────┐  │
│  │  WalletView │  │  RadarView  │  │     ChatView        │  │
│  └──────┬──────┘  └──────┬──────┘  └──────────┬──────────┘  │
│         │                │                     │             │
│  ┌──────┴────────────────┴─────────────────────┴──────────┐ │
│  │                    ViewModels                           │ │
│  │  WalletViewModel │ MeshViewModel │ ChatViewModel        │ │
│  └──────────────────────────┬──────────────────────────────┘ │
└─────────────────────────────┼────────────────────────────────┘
                              │
┌─────────────────────────────┼────────────────────────────────┐
│                     StealthCore Package                       │
│  ┌──────────────────────────┴──────────────────────────────┐ │
│  │              MeshNetworkManager (Coordinator)            │ │
│  └──────────────────────────┬──────────────────────────────┘ │
│         ┌───────────────────┼───────────────────┐            │
│         ▼                   ▼                   ▼            │
│  ┌─────────────┐    ┌─────────────┐    ┌─────────────────┐  │
│  │ BLEMeshSvc  │    │ StealthWallet│   │ SettlementSvc   │  │
│  │ (CoreBT)    │    │ Manager      │   │ (Auto-settle)   │  │
│  └──────┬──────┘    └──────┬───────┘   └────────┬────────┘  │
│         │                  │                     │           │
│  ┌──────┴──────────────────┴─────────────────────┴────────┐ │
│  │                      Crypto Layer                       │ │
│  │  SodiumWrapper │ MLKEMWrapper │ DoubleRatchetEngine     │ │
│  └──────────────────────────┬──────────────────────────────┘ │
└─────────────────────────────┼────────────────────────────────┘
                              │
                              ▼
                    ┌─────────────────┐
                    │  Solana Devnet  │
                    │  (Helius RPC)   │
                    └─────────────────┘

API Reference

Generate Stealth Identity

import StealthCore

// Generate keypair with post-quantum support
let keyPair = try StealthKeyPair.generate(enablePostQuantum: true)

// Share meta-address via QR code
let metaAddress = keyPair.hybridMetaAddressString

Send to Stealth Address

// Derive one-time address from meta-address
let result = try StealthAddressGenerator.generateStealthAddressAuto(
    metaAddressString: recipientMetaAddress
)

// result.stealthAddress - transaction destination
// result.ephemeralPublicKey - include in memo
// result.isHybrid - whether PQ was used

Scan for Payments

let scanner = StealthScanner(keyPair: myKeyPair)

// Scan transaction
if let payment = try scanner.scanTransaction(
    stealthAddress: destination,
    ephemeralPublicKey: memoData,
    mlkemCiphertext: ciphertext  // optional for hybrid
) {
    // payment.spendingPrivateKey can sign from stealth address
}

Security Model

Threat	Mitigation
Relay reads payment	Payload encrypted to recipient's viewing key (AES-256-GCM)
Relay modifies tx	Transaction pre-signed; tampering invalidates signature
Replay attack	Message IDs + deduplication cache (1-hour TTL)
Quantum adversary	Hybrid X25519 + ML-KEM 768 (NIST Level 3)
Key extraction	iOS Keychain with kSecAttrAccessibleWhenUnlockedThisDeviceOnly
Device compromise	Biometric auth for spending operations

Tech Stack

• Swift 5.9+ / iOS 26+ deployment target
• SwiftUI with MVVM architecture
• CoreBluetooth for BLE mesh networking
• CryptoKit for X25519, AES-256-GCM, SHA256, MLKEM768
• swift-sodium-full for ed25519 point arithmetic
• Solana.Swift for blockchain interaction

References

• EIP-5564: Stealth Addresses
• Post-Quantum Stealth Address Protocols
• NIST FIPS 203: ML-KEM Standard
• Apple CryptoKit MLKEM768

License

MIT License - see LICENSE for details.

---

Built for the Solana Private Payments Hackathon
