Client Credentials Grant Type

This sample lets you request an OAuth token from Apigee using the OAuth 2.0 client credentials grant type flow.

About client credentials

Most typically, this grant type is used when the app is also the resource owner. For example, an app may need to access a backend cloud-based storage service to store and retrieve data that it uses to perform its work, rather than data specifically owned by the end user. This grant type flow occurs strictly between a client app and the authorization server. An end user does not participate in this grant type flow.

How it works

With the client credentials grant type flow, the client app requests an access token directly by providing its client ID and client secret keys. These keys are generated when you create a Developer App in Apigee. Apigee validates the credentials and returns an access token to the client. The client can then make secure calls to the resource server.

The API is called like this, where the client ID and secret are Base64-encoded and used in the Basic Auth header:

curl -H "Authorization: Basic <base64-encoded key:secret>" https://your-api-url.com/oauth/token?grant_type=client_credentials

Implementation on Apigee

The client credentials sample uses one policy that executes on Apigee : An OAuthV2 policy to generate the access token. The policy is attached to the /token endpoint (a custom flow on Apigee).

Screencast

Prerequisites

1. Provision Apigee X
2. Configure external access for API traffic to your Apigee X instance
3. Access to deploy proxies, create products, apps and developers in Apigee
4. Make sure the following tools are available in your terminal's $PATH (Cloud Shell has these preconfigured)
   • gcloud SDK
   • unzip
   • curl
   • jq
   • npm

(QuickStart) Setup using CloudShell

Use the following GCP CloudShell tutorial, and follow the instructions.

Setup instructions

1. Clone the apigee-samples repo, and switch the oauth-client-credentials directory

git clone https://github.com/GoogleCloudPlatform/apigee-samples.git
cd apigee-samples/oauth-client-credentials

2. Edit the env.sh and configure the ENV vars

• PROJECT the project where your Apigee organization is located
• APIGEE_HOST the externally reachable hostname of the Apigee environment group that contains APIGEE_ENV
• APIGEE_ENV the Apigee environment where the demo resources should be created

Now source the env.sh file

source ./env.sh

3. Deploy Apigee API proxies, products and apps

./deploy-oauth-client-credentials.sh

Testing the Client Credentials Proxy

To run the tests, first retrieve Node.js dependencies with:

npm install

Ensure the following environment variables have been set correctly:

• PROXY_URL
• APP_CLIENT_ID
• APP_CLIENT_SECRET

and then run the tests:

npm run test

Example Requests

For additional examples, including negative test cases, see the oauth-client-credentials.feature file.

OAuth Bearer Token (RFC 6749)

First obtain a short-lived opaque access token using the token endpoint. Instructions for how to find application credentials can be found here. If the deployment has been successfully executed, you will see the oauth-client-credentials-app created for testing purposes.

curl -v POST https://$APIGEE_HOST/v1/samples/oauth-client-credentials/token -u $APP_CLIENT_ID:$APP_CLIENT_SECRET -d "grant_type=client_credentials"

Note: Under normal circumstances, avoid providing secrets on the command itself using -u

Copy the value of the access_token property from the response body of the previous request and include it in the following request:

curl -v GET https://$APIGEE_HOST/v1/samples/oauth-client-credentials/resource -H "Authorization: Bearer access_token"

Cleanup

If you want to clean up the artifacts from this example in your Apigee Organization, first source your env.sh script, and then run

./clean-up-oauth-client-credentials
